Indoor · Micro LED
Vista Series indoor Micro LED video wall
Our flagship Micro LED for boardrooms, control rooms and premium spaces where people sit close to the screen. Deep blacks, high contrast and even colour from edge to edge.
- Pixel pitch
- P0.93–P1.87Pixel pitch
- Nits brightness
- Up to 2,000Nits brightness
- Refresh rate
- 3,840 HzRefresh rate
- Viewing angle H / V
- 170°Viewing angle H / V
Overview
Micro LED clarity at close range
Fine pixel pitches and high contrast keep text, dense data and video sharp when the audience is only a couple of metres away.
Slim 16:9 cabinets (600 × 337.5 mm) tile into native 2K, 4K and 8K canvases with no bezels, and front maintenance lets the wall sit flush.
- 16:9 cabinets for native 2K, 4K and 8K walls
- Brightness options from 600 to 2,000 nits
- Adjustable colour temperature (7,500 K)
In detail
Key features
Why Vista Series
Ultra-fine pixel pitch
From P0.93 for crisp detail at short viewing distances.
High contrast
Deep blacks and saturated colour for premium content.
Robust surface
Protected LEDs resist knocks and are simple to clean.
Front maintenance
Modules come out from the front, so the wall can sit flush.
Applications
Where Vista is used
Installations where image quality is part of the brand: boardrooms, receptions, broadcast studios and experience centres.
- Executive boardrooms and briefing centres
- Control and operations rooms
- Broadcast studios and experience centres
- Luxury retail and reception walls
Specifications
The numbers
Typical values per model. Ask us for the full datasheet or a custom configuration.
| Model | Pixel pitch (mm) | Cabinet resolution | Brightness (nits) | Scan | Power max / avg (W/m²) |
|---|---|---|---|---|---|
| GV-09LL | 0.93 | 640 × 360 | 600 | 1/54 | 370 / 125 |
| GV-12LL | 1.25 | 480 × 270 | 600 | 1/60 | 350 / 120 |
| GV-15LL | 1.56 | 384 × 216 | 600 | 1/54 | 350 / 120 |
| GV-18LL | 1.87 | 320 × 180 | 600 | 1/40 | 325 / 110 |
| GV-12LM | 1.25 | 480 × 270 | 1,000 | 1/60 | 330 / 110 |
| GV-15LM | 1.56 | 384 × 216 | 1,000 | 1/54 | 310 / 105 |
| GV-09LH | 0.93 | 640 × 360 | 1,200 | 1/36 | 300 / 100 |
| GV-12LH | 1.25 | 480 × 270 | 1,200 | 1/27 | 250 / 85 |
| GV-15MH | 1.56 | 384 × 216 | 1,500 | 1/54 | 420 / 140 |
| GV-18MH | 1.87 | 320 × 180 | 1,500 | 1/45 | 390 / 130 |
| GV-09HH | 0.93 | 640 × 360 | 2,000 | 1/45 | 480 / 160 |
| GV-12HH | 1.25 | 480 × 270 | 2,000 | 1/45 | 420 / 140 |
Projects
Vista Series in the field
SBM · Conference room
Conference room LED video wall for SBM
A VISTA Series P1.2 wall for executive meetings, presentations and video conferencing.
VISTA Series P1.2 View project
Majmaa Complex · Four auditoriums
Auditorium LED video walls for Majmaa Complex
Four auditoriums, one VISTA Series P1.8 standard across the whole complex.
VISTA Series P1.8 View project
Dual control rooms · Two control rooms
VISTA COB LED video walls for two control rooms
Bezel-free VISTA COB walls for real-time monitoring across two control rooms.
VISTA COB View project
Request a quote
Get a quote for Vista Series
Tell us about the space, the size you have in mind and your timeline. We reply with a recommended model and pitch, a layout drawing and a quotation.
- sales@gravitytech.uk
- +44 20 3813 0970
- Reply within one business day
